Intelligent software and control systems for CNC tube bending machines
Control systems for tube bending machines are a core component of modern bending technology. They ensure precise motion sequences, reproducible results, and efficient control of complex bending processes.
The NxG control system is the heart of our CNC tube bending machines and is specifically designed to make complex tube bending processes faster, more efficient, and safer. Simple and intuitive operation.
It offers simple and intuitive operation and creates optimal conditions for single-part production, series manufacturing, and fully automated production cells – always precise, transparent, and digitally networked.
Vorteile unserer Steuerungen für Rohrbiegemaschinen
The NxG control system for tube bending machines combines high performance, intuitive operation, and maximum process reliability. It supports efficient tube bending processes – from single parts to fully automated series production.
-
Up to 35% shorter cycle times
-
Intuitive HMI for fast operation
-
Offline bending simulation for secure program preparation
-
Extensive feature set – without additional software costs
-
Industry 4.0–ready and network-capable
-
Modular control system: optionally expandable to cell control
Key features of the NxG control system for tube bending machines
Performance & Precision
More output with maximum repeatability
- Up to 35% shorter cycle times
- Simultaneous axis movements
- Parameter adjustments during bending
- High-performance drives for consistent series quality
Simulation & Programming
Plan securely. Transfer easily. Avoid errors.
- Offline bending simulation
- Visualization of bending paths & collision zones
- Drag-and-drop transfer
- Import of STEP, STL, and XYZ
- Fast programming via TOB
Operation & HMI
Intuitive, visual, quickly learnable
- Visual, clearly structured interface
- Storage of all programs & tool data
- Image-guided user operation
- Instant help with specific suggestions
- AI-Bend: AI-powered assistance function
Connectivity & Industry 4.0
Connected. Future-proof. Efficient.
- RFID tool identification
- Predictive maintenance
- Digital twin
- Interfaces for measuring cells, printers & additional systems
Expandable to cell control
The NxG control system can be used not only as a control system for tube bending machines, but also as the central control unit of an entire production cell. This allows the bending machine, magazine, robot, endforming or cutting units to be integrated without any additional external control system.
Beyond this, Schwarze‑Robitec offers far more than pure control software: we provide the appropriate hardware, deliver turnkey solutions, and take care of the complete networking of all components. We also implement customer-specific requirements in the form of tailored solutions – from planning and integration through to commissioning of the entire system.
Advanced functions of control systems for tube bending machines
Additional functions of the NxG control system for greater transparency, process reliability, and efficiency throughout the entire production process.
Visualization &
bending simulation
Direct visualization of motion sequences and collision-relevant areas.
Ideal for the safe planning of complex geometries even before
Intelligent tool change (RFID)
Tools are automatically identified and matched with the correct program.
Integrated Poka‑Yoke logic ensures maximum process reliability in everyday production.
Predictive
Maintenance
The control system for tube bending machines detects critical components at an early stage and continuously monitors their condition.
Maintenance intervals are recommended predictively – unplanned downtime is reduced.
Machine connectivity
& OPC UA
OPC UA‑based interface for providing machine status data and error messages across the network.
Supports integration with higher-level systems such as MES or ERP for transparent condition and process monitoring.
Talk to us about your project
Would you like to make your tube bending processes more efficient, faster, or more digital?
We would be happy to advise you on the right NxG control and software solution.
